The Rotel S14 Integrated Network Streamer is an all-in-one solution providing the ultimate in convenience to the near limitless catalog of music delivering 150 Watts of Class AB power.
Album artwork on the front display, included remote, simple operation and intuitive setup ensures the S14 becomes the heart of your music system.
- Intermodulation Distortion (60Hz:7kHz, 4:1): <0.03%
- Damping Factor: 400
Input Sensitivity
- Line Level Inputs: 200mV
- Digital Inputs: -20dBfs
Input Impedance
- Line Level Inputs: 47kO
- Digital Inputs: 75O
Input Overload
- Line Level Inputs: 4.5V
- Tone Controls: ±10dB at 100Hz / 10kHz
- Coax/Optical Digital Input Signals: SPDIF LPCM (Up to 24-bit/192kHz)
PC-USB
- USB Audio Class 2.0 (up to 24-bit/384kHz)*
*Driver installation required
- MQA and MQA Studio (up to 24-bit/384kHz )
- Total Harmonic Distortion (THD): <0.04%
Frequency Response
- Line Level Inputs: 10Hz - 100kHz, ±0.5dB
- Digital Inputs: 10Hz - 90kHz, ±2.0dB, Max
S/N Ratio (IHF "A" Weighted)
- Line Level Inputs: 100dB
- Digital Inputs: 98dB
Power
- Power Requirements: 230V, 50Hz
- Power Consumption: 280W
- Standby Power Consumption: <0.5W
- BTU RATING (4O, 1/8th power): 733 BTU/h
- Maximum Power Output: 150W/Ch (4O)
- Continuous Power Output: 80W/Ch (8O)
Size
- Dimensions (W × H × D): 430 × 93 × 345mm (17" × 3 5/8" × 13 1/2")
- Front panel height: 80mm (3.15")
- Net Weight: 9.15kg (20.17lbs.)
